    Wire 2.7mm Gabion Mesh Machine Straight and Reverse Twisted Wire Mesh Machinery

    Ask Lasest Price
    Brand Name : Konson
    Certification : CE, ISO9001, SGS test, Chinese Patent
    Model Number : KS80100-4.0
    Price : Competitive price
    Delivery Time : within 30 days in receiving prepayment
    Payment Terms : L/C, T/T
    Supply Ability : 10 Sets per Month
    • Product Details
    • Company Profile

    Wire 2.7mm Gabion Mesh Machine Straight and Reverse Twisted Wire Mesh Machinery

    Wire 2.7mm Gabion Mesh Machine Straight and Reverse Twisted Wire Mesh Machinery


    Introduction

    Konson brand gabion mesh machine is the professional equipments for producing gabion basket, gabion wire mesh, it is also known as heavy type hexagonal wire netting machine.

    Gabion mesh machine includes four main standard parts: Main netting machine, Winding machine, Wire tension device and Spiral coiling machine, it can produce gabions of various widths and mesh sizes.



    KS Gabion Machine:

    1. Model: KS80100-4.0

    2. Mesh size: 80x100mm

    3. Twist: Double twist

    4. Wire diameter: 1.6-4.0mm

    5. PVC wire diameter: 3.0-5.5mm

    6. Max. width: 4300mm

    7. Spindle Speed:25r/min

    8. Theoretic output: 3.5m/min

    9. Motor power: 22.0kw

    10. Weight: 15MT

    11. Dimensions: 8100mm x 1500mm x 2180mm

    Specification:

    KS machine is designed to produce hexagonal mesh of various widths and sizes:

    MODEL

    MESH SIZE

    MAX.WIRE DIA.

    MAX WIDTH

    PRODUCING RATE

    KS6080-2.4

    60X80

    mm

    3.0mm

    2400mm

    >3.3 m/min

    KS6080-3.2

    3.5mm

    3200mm

    KS6080-4.0

    3.5mm

    4300mm

    KS80100-2.4

    80X100

    mm

    3.5mm

    2400mm

    >3.5 m/min

    KS80100-3.2

    3.5mm

    3200mm

    KS80100-4.0

    4.0mm

    4300mm

    KS100120-2.4

    100X120

    mm

    3.5mm

    2400mm

    >3.5 m/min

    KS100120-3.2

    3.5mm

    3200mm

    KS100120-4.0

    4.0mm

    4300mm

    KS120150-2.4

    120X150

    mm

    4.0mm

    2400mm

    >3.8 m/min

    KS120150-3.2

    4.0mm

    3200mm

    KS120150-4.0

    4.0mm

    4300mm


    4. Optional Machines:
