Hexagonal Double Twisted Gabion Stone Baskets / Gabion Mattresses , Monolithic Structure
Gabion basket mattress is a structure made of hexagonal double twisted wire mesh, gabion mattresses are filled with stones at the project site to form flexible and permeable, monolithic structures such as river bank protection and channel linings for erosion control.Gabion mattresses are divided into uniformly partitioned cells by internal diaphragms.
1. Economical. Just fill the stone into the gabions and seal it.
2. Simple installation. No special technology needed.
3. Weather proof under natural destroy, corrosion resistance.
4. Sludge in the stones is good for plant growing. Mixed to form a
integrity with the natural environment.
5. Good permeation can prevent the damage by hydrostatic.
6. Less transportation freight. It can be folded together for
transportation and further installation.
7. No collapse even under big scope of deformation.
Gabion Basket size:
Standard sizes 6x2x0.17m 6x2x0.23m 6x2x0.30m 3x2x0.17m 3x2x0.23m
3x2x0.30m
Mesh size(mm):60x80mm, 80x100mm, 100x120mm, 120x150mm
Wire diameter:2.2mm/3.2mm, 2.4mm/3.4mm, 2mm/3.0mm
We can manufacture as client's demand.
Gabion mattresses specification:
Long(m) | Width(m) | High(m) | Mesh type(mm) |
3m | 2m | 0.15-0.20-0.25 | 80x100 |
4m | 2m | 0.15-0.20-0.25 | 80x100 |
5m | 2m | 0.15-0.20-0.25 | 80x100 |
6m | 2m | 0.15-0.20-0.25 | 80x100 |
3m | 2m | 0.17-0.23-0.30 | 60x80 |
4m | 2m | 0.17-0.23-0.30 | 60x80 |
5m | 2m | 0.17-0.23-0.30 | 60x80 |
6m | 2m | 0.17-0.23-0.30 | 60x80 |
All sizes and dimensions are nominal. Tolerances of ± 3% of the width, length,
and ±2.5 cm of the height shall be permitted.
|
|
