Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm

Konson Industrial Co., Ltd.
Contact Now
    Buy cheap Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm from wholesalers

    Buy cheap Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm from wholesalers
    • Buy cheap Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm from wholesalers
    • Buy cheap Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm from wholesalers

    Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm

    Ask Lasest Price
    Brand Name : Konson
    Model Number : KS80100-4.0
    Certification : CE, ISO9001, SGS test, Chinese Patent
    Price : Competitive price
    Payment Terms : L/C, T/T
    Supply Ability : 10 Sets per Month
    Delivery Time : within 30 days in receiving prepayment
    • Product Details
    • Company Profile

    Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm


    Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm


    KS Gabion Machine:

    Dimensions8100mm x 1500mm x 2180mm
    ModelKS80100-4.0
    Mesh size80x100mm
    TwistDouble twist
    Wire diameter1.6-4.0mm
    PVC wire diameter3.0-5.5mm
    The Max. width4300mm
    Spindle Speed25r/min
    Theoretic output3.5m/min
    Motor power22.0kw
    Weight15MT



    Gabion mesh machine is also called heavy duty hexagonal wire mesh machine or gabion box machine, which is to produce the hexagonal wire mesh for reinforcement stone box use to protect and support the seawall,hillsides,road and bridge,reservoirs and other civil engineering.


    Capacity of hexagonal wire mesh machine
    Also called gabion mesh machine

    • Hexagonal wire mesh machine is professional equipment to produce hexagonal wire mesh
    • This machine adopts PLC automatic control,which have smooth operation,low noise and high effficiency charactersics
    • Wire diameter,mesh size and width are adjustable


    Gabion Machine Usage

    1. Widely used for fencing,residential and landscape protection
    2. It is also good material which is used to make stone wire mesh cages,which are widely used to protect and support the seawall,hillsides,road and bridge,reservoirs and other civil engineering.



    Main Features
    1. Wire feeding from wire coilers automatically, high production.
    2. Schneider/Siemens electric components+ touch screen.
    3. Double driving blocks, high speed and smooth running.
    4. New welding cross beam, high stability.
    5. Weaving one net or several nets at the same time.
    6. Complete production line of gabion mesh machine.






    Installation and service:

    We can dispatch our engineers to your factory for the installation of the machine and the training. About the detailed information of after-sales service, you can contact with our sales personal.

    The gabion mesh machine, is the professional equipment that produces hexagonal wire netting, its product extensively used for petroleum, building, farming and chemical engineering industry, keep warm piping and other piping, be also used for rounding column, residence and park greening safeguard etc..


    Gabion mesh is still more available to manufacture the gabion mesh box and extensively used for safeguard and backing sea dike, hillside, road , bridge and reservoir and others, it is the best material of the flood control at the same time.

    Product Tags:

    gabion mesh machine



    wire mesh machine


    Quality Wire Diameter 1.6-4.0mm Automated Gabion Machine Smooth Running Mesh size 80x100mm for sale
