| Brand Name : | Konson |
| Model Number : | KS80100-3.2 |
| Certification : | CE, ISO9001, SGS, ASTMA, EN,BS Standard. |
| Price : | Discuss in mail |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 10Sets per Month |
| Delivery Time : | within 30 days in receiving prepayment |
Protecting Mesh Gabion Box Machine Simple Construction Corrosion Resistance
Gabion Box Machine Main machine
Netting straightening machine
Netting cutting machine/mesh cutting machine/mesh sheet cutting machine
Edge winding up machine/gabion mesh crimped machine
Gabion packing machine/Gabion mesh press machine
Wire pay off system
PVC coating machine/PVC coating line/ PVC coated machine
Wire straightening and cutting machine/Wire rod straightening and
cutting machine
Gabion Box Machine Brief Introduction
A set of gabion box machine includes four main parts: Mesh weaving machine, roll mesh machine, coiling spring machine, warping machine.
1. The gabion box machine is widely used in oil, construction, raising, chemical industry, warming piping and
etc. It is also used in fence, apartment and greening.
2. The mesh making machine can be used in protect seawall, hillside, road, bridge and civil engineering.
3. It is one of the best against flooding materials.
Gabion Box Machine
Gabion Box Machine which is ideal for creating different types of boxes in diverse shapes and sizes. It is used in various packaging industries due to its high performance efficiency and timely execution.
In addition to this, the said Gabion Box Machine is robust in construction and provides simple operations, smooth functioning, longer functional life, high strength etc.
This machine requires less power consumption and low maintenance. It is known for its anti-corrosion nature, dimensional accuracy and seamless finishing. You can avail this in different specifications and designs as per the requirement.
Gabion Box Machine Specification:
| MODEL | MESH SIZE | MAX.WIRE DIA. | MAX WIDTH | PRODUCING RATE | MOTOR POWER |
| KS6080-2.4 | 60X80mm | 3.0mm | 2400mm | >4.8 m/min | 15 kw |
| KS6080-3.2 | 2.8mm | 3200mm | 18.5 kw | ||
| KS6080-4.0 | 2.8mm | 4000mm | 22 kw | ||
| KS80100-2.4 | 80X100mm | 3.0mm | 2400mm | >4.9 m/min | 17 kw |
| KS80100-3.2 | 3.0mm | 3200mm | 17 kw | ||
| KS80100-4.0 | 3.0mm | 4000mm | 18.5 kw | ||
| KS80100-4.3 | 3.4mm | 4300mm | 19 kw | ||
| KS100120-2.4 | 100X120mm | 3.2mm | 2400mm | >4.3 m/min | 19 kw |
| KS100120-3.2 | 3.2mm | 3200mm | 19 kw | ||
| KS100120-4.0 | 3.0mm | 4000mm | 19 kw | ||
| KS120150-2.4 | 120X150mm | 4.0mm | 2400mm | >4.4 m/min | 17 kw |
| KS120150-3.2 | 4.0mm | 3200mm | 19 kw | ||
| KS120150-4.0 | 3.5mm | 4000mm | 19 kw |
Range of supply
| Main netting machine | 1 Set |
| Winding machine | 1 Set |
| Wire tension device | 1 Set |
| Air compressor | 1 Set |
| Standard spareparts | 1 Set |
| Lubrication pump | 1 Set |
The model in picture is automatic gabion mesh machine
We can manufacture especial size as your request, User satisfaction
is our unremitting goal!
|
|
