Fence Mesh Gabion Box Machine Producing Rate > 4.4 M/ Min Ks120150-4.0
Gabion Box Machine Brief Introduction:
Gabion Box Machine which is ideal for creating different types of boxes in diverse shapes and sizes. It is used in various packaging industries due to its high performance efficiency and timely execution.
In addition to this, the said Gabion Box Machine is robust in construction and provides simple operations, smooth functioning, longer functional life, high strength etc.
This machine requires less power consumption and low maintenance. It is known for its anti-corrosion nature, dimensional accuracy and seamless finishing. You can avail this in different specifications and designs as per the requirement.
Gabion Box Machine Description:
The series gabion mesh machines have been designed to make gabion mesh of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, galfan coated wire is available.
Gabion Box Machine Gabion Application:
Gabion Machine widely used in oil, construction, raising, chemical industry warming piping, etc. It is also used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside, road, bridge and civil engineering. It is one of the best against flooding material.
The gabion box machine is widely used in oil, construction, raising, chemical industry, warming piping and etc.
It is also used in fence, apartment and greening. The hexagonal wire netting can be used in protect sea wall, hillside, road, bridge and civil engineering. It is one of the best against flooding materials.
Specification:
| MODEL | MESH SIZE | MAX.WIRE DIA. | MAX WIDTH | PRODUCING RATE | MOTOR POWER |
| KS6080-2.4 | 60X80mm | 3.0mm | 2400mm | >4.8 m/min | 15 kw |
| KS6080-3.2 | 2.8mm | 3200mm | 18.5 kw | ||
| KS6080-4.0 | 2.8mm | 4000mm | 22 kw | ||
| KS80100-2.4 | 80X100mm | 3.0mm | 2400mm | >4.9 m/min | 17 kw |
| KS80100-3.2 | 3.0mm | 3200mm | 17 kw | ||
| KS80100-4.0 | 3.0mm | 4000mm | 18.5 kw | ||
| KS80100-4.3 | 3.4mm | 4300mm | 19 kw | ||
| KS100120-2.4 | 100X120mm | 3.2mm | 2400mm | >4.3 m/min | 19 kw |
| KS100120-3.2 | 3.2mm | 3200mm | 19 kw | ||
| KS100120-4.0 | 3.0mm | 4000mm | 19 kw | ||
| KS120150-2.4 | 120X150mm | 4.0mm | 2400mm | >4.4 m/min | 17 kw |
| KS120150-3.2 | 4.0mm | 3200mm | 19 kw | ||
| KS120150-4.0 | 3.5mm | 4000mm | 19 kw |
Range of supply
| Main netting machine | 1 Set |
| Winding machine | 1 Set |
| Wire tension device | 1 Set |
| Air compressor | 1 Set |
| Standard spareparts | 1 Set |
| Lubrication pump | 1 Set |
The model in picture is automatic gabion mesh machine
We can manufacture especial size as your request, User satisfaction is our unremitting goal!
|
|
