Double Twist Hexagonal Wire Netting Machine Wire Diameter 1.6-4.0mm
25r/Min
Features:
1. One set of main machine can only produceone mesh size.
2. One set of main machine can make severalwire diameters.
3. You can weave two or three net with thesame machine.
4. Adopt the principle of clockwise and counterclockwise
twisting;no need to makeiron wire spring form to increase
productivity
Hexagonal Wire Netting Machine
1. Model: KS80100-4.0
2. Mesh size: 80x100mm
3. Twist: Double twist
4. Wire diameter: 1.6-4.0mm
5. PVC wire diameter: 3.0-5.5mm
6. Max. width: 4300mm
7. Spindle Speed:25r/min
8. Theoretic output: 3.5m/min
9. Motor power: 22.0kw
10. Weight: 15MT
11. Dimensions: 8100mm x 1500mm x 2180mm.
Specification
| MODEL | MESH SIZE | MAX.WIRE DIA. | MAX WIDTH | PRODUCING RATE |
| KS6080-2.4 | 60X80 mm | 3.0mm | 2400mm | >3.3 m/min |
| KS6080-3.2 | 3.5mm | 3200mm | ||
| KS6080-4.0 | 3.5mm | 4300mm | ||
| KS80100-2.4 | 80X100 mm | 3.5mm | 2400mm | >3.5 m/min |
| KS80100-3.2 | 3.5mm | 3200mm | ||
| KS80100-4.0 | 4.0mm | 4300mm | ||
| KS100120-2.4 | 100X120 mm | 3.5mm | 2400mm | >3.5 m/min |
| KS100120-3.2 | 3.5mm | 3200mm | ||
| KS100120-4.0 | 4.0mm | 4300mm | ||
| KS120150-2.4 | 120X150 mm | 4.0mm | 2400mm | >3.8 m/min |
| KS120150-3.2 | 4.0mm | 3200mm | ||
| KS120150-4.0 | 4.0mm | 4300mm |
OPERATIONS
Hexagonal Wire Netting Machine has a circular pinion holder on the
front and rear of the machine.
The wires which are fed from the bobbins and also from the spiral
coil (prepared in spiral coiling machine) placed on the front and
rear rack of the machine produces the netting.
The net is pulled out by the take-up roller with stands on the
surface of the machine and wound automatically on the winding
roller.
When the length of netting reaches the predetermined length, the
same is cut and removed from the roller.
The complete operation is then repeated.
Description
1. PLC + Touch screen, easy operation.
2. Servo motor transmission, running fast, shock-resistance, smooth running, low noise, much
better than mechanical transmission.
3. Inching / Single-step control button.
4. Grid counter + alarm to stop machine (when wire/ mesh broken, or preset numbers into
zero).
5. Automatically wind up mesh into rolls.
6. Automatic central lubrication system to reduce machine damages.
7. The machine can weave several mesh rolls at same time for different mesh width.
KS series machine has the feature of rational design, simple
structure, smooth running, excellent performance, reliable
operation and convenient maintenance.
Advantages:
A1. CE certificate.
A2. QC system & timely delivery.
A3. New drive mode.
A4. Automatic oil system.
A5. Overload protect clutch.
A6. High-efficiency: theoretic output = 3.5m/min.
A7. Turbine protection system (Option).
A8. Infrared ray safety (Option).
A9. Automatic stop system (Option).
A10. All of the core parts of machines are processed by our own
factory, so the quality can be ensured.
A11. KONSON offer better after-sale service. We can provide 12
months guarantee for all the equipments, we will arrange our
engineer to install the machines in your factory and teach your
workers how to produce, we will also send accessories and spare
parts without any cost.
|
|
