| Brand Name : | Konson |
| Model Number : | KS120150-4.0 |
| Certification : | CE, ISO9001, SGS, ASTMA, EN, BS standard. |
| Price : | Discuss in mail |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 10 Sets per Month |
| Delivery Time : | within 30 days in receiving prepayment |
PLC Control System Hexagonal Wire Netting Machine 95% Aluminium Alloy Wire 22kw
Hexagonal Wire Netting Machine :
1. PLC + Touch screen, easy operation.
2. Servo motor transmission, running fast, shock-resistance, smooth running, low noise, much
better than mechanical transmission. 150m/h
3. Inching / Single-step control button.
4. Grid counter + alarm to stop machine (when wire/ mesh broken, or preset numbers into
zero).
5. Automatically wind up mesh into rolls.
6. Automatic central lubrication system to reduce machine damages.
7. The machine can weave several mesh rolls at same time for different mesh width.
Features
1. One set of main machine can only produceone mesh size.
2. One set of main machine can make severalwire diameters.
3. You can weave two or three net with thesame machine.
4. Adopt the principle of clockwise and counterclockwise
twisting;no need to makeiron wire spring form to increase
productivity
Specification
| MODEL | MESH SIZE | MAX.WIRE DIA. | MAX WIDTH | PRODUCING RATE |
| KS6080-2.4 | 60X80 mm | 3.0mm | 2400mm | >3.3 m/min |
| KS6080-3.2 | 3.5mm | 3200mm | ||
| KS6080-4.0 | 3.5mm | 4300mm | ||
| KS80100-2.4 | 80X100 mm | 3.5mm | 2400mm | >3.5 m/min |
| KS80100-3.2 | 3.5mm | 3200mm | ||
| KS80100-4.0 | 4.0mm | 4300mm | ||
| KS100120-2.4 | 100X120 mm | 3.5mm | 2400mm | >3.5 m/min |
| KS100120-3.2 | 3.5mm | 3200mm | ||
| KS100120-4.0 | 4.0mm | 4300mm | ||
| KS120150-2.4 | 120X150 mm | 4.0mm | 2400mm | >3.8 m/min |
| KS120150-3.2 | 4.0mm | 3200mm | ||
| KS120150-4.0 | 4.0mm | 4300mm |
Hexagonal Wire Netting Machine Introduction:
KONSON hexagonal wire netting machine is designed to make gabion mesh of various widths and mesh sizes. The possible coatings are heavily galvanized and zinc. For high corrosion resistance, zinc and PVC, galfan coated wire is available.
KONSON exported gabion machine to Russia,Bosina,Poland,Croatia,Bulgaria,Algeria,Morocco,Ethiopia,Venezuela and etc.
The KS series gabion mesh machines include four main standard parts: Main netting machine, winding machine, wire tension device and spiral coiling machine, it can produce gabions of various widths and mesh sizes.
Konson gabion machine strict with CE certification has been exported to more than 40 countries before. It is our honor to provide the machine to you!
KS series machine has the feature of rational design, simple structure, smooth running, excellent performance, reliable operation and convenient maintenance.
Advantages:
A1. CE certificate.
A2. QC system & timely delivery.
A3. New drive mode.
A4. Automatic oil system.
A5. Overload protect clutch.
A6. High-efficiency: theoretic output = 4.15m/min.
A7. Turbine protection system (Option).
A8. Infrared ray safety (Option).
A9. Automatic stop system (Option).
A10. All of the core parts of machines are processed by our own
factory, so the quality can be ensured.
A11. KONSON offer better after-sale service. We can provide 12
months guarantee for all the equipments, we will arrange our
engineer to install the machines in your factory and teach your
workers how to produce, we will also send accessories and spare
parts without any cost.
Installation and service:
We can dispatch our engineers to your factory for the installation of the machine and the training. About the detailed information of after-sales service, you can contact with our sales personnel.
